Confectionary Plants (Toffee - Candy- Lollipop Making Plants)

SL NO.

CANDY PLANT                                                                     PARTICULARS

QTY REQD.

1.

Batch Former Capacity 60-65 Kgs.

• Stainless Steel Rollers
• Electric Reverse & Forward system
• Motorized Lifting
• SS / Gun Metal Contact Parts
• 0.5 H.P,  AC motor (for Rev/Forward)
• 1 HP, AC motor for Lifting
• Heater 1000 Watt for batch warming

1No.

2.

Rope Sizer Three Stage

• Nickel Chrome MS Sizing Wheels
• SS/GM Rope guides, Rope Running Plates etc.
• Drive 1 H.P. AC Motor

1No.

3.

12” Plast-O-Plast Candy Forming Machine with 1 No. Die

• Capacity 2000 Kgs./Shift
• Sharp Design
• Seamless Uniform Candy
• Very Low scrap formation
• Two Speeds
• 2 HP, AC Motor

1No.

4.

Three-way Cooling Conveyor

• Belt widths 4”, 8”, 12”
• Galvanized Wiremesh Conveyor Belts
• Drive from Forming Machine
• Blower with 3 HP, AC Motor
• Scrap Collecting Trays

1No.

5.

Electrical Control Panel

• Single Point plant controlling
• Standard Make Electrical Equipments
• Volt Meter, Amp Meter
• Push button Operation, Timer for Batch former
• MCB, Indicator Lamp etc.
• 1 H.P. AC drive for Rope Sizer

1No.

6.

Cooling Plate for Kneading Table (1No.)

 Water Circulation cooling System Suitable for Kneading table

1No.

SL NO.

CANDY PLANT                                                                     PARTICULARS

QTY REQD.

7.

Rotary Kneading Table

 Capacity 50 Kgs. Batch

 Stainless Steel Lined Top

 Water Cooled Stainless Steel Contact Parts

 Motor: 5hp

1No.

8.

Stainless Steel Vacuum Batch Cooker

• Capacity 50 Kgs./batch
• Stainless Steel 304 Contact Parts
• Anchor Type Stirrer
• Water Cooled Vacuum Pot
• Steam Pressure Gauge, Temp. Gauge, Safety valves
• Water Ring Vacuum Pump with 5 HP, AC motor

3 HP Dual Speed 960/1440, AC Motor for stirrer Panel Board with MCB, Amp Meter, Volt Meter and

Digital temperature indicator and other standard electrical

1No.
